processor

Intel LGA1155 pin series processor

Southbridge

H61 Chipset series

memory

technology

Dual-channel DDR3 1066/1333/1600/1866MHZ

maximum capacity

16G

Memory slot

2*240Pin  DDR3

Post I/O

Display interface

1 VGA；; 1 HDMI

Ethernet

1 Realtek 100 MB network card

Audio

1 (Mic-in, Line-out, Line-in)

USB port

USB 2.0*6

Internal connector

USB2.0

4 (one FUSB can transfer out two USB2.0 interfaces);

ATXPWR interface

1 standard 1x4PIN power socket; 1 standard 1x24PIN power socket

Audio

1 2*5Pin pin

serial ata

4 SATA interfaces (SATA2.0 * 4)

M.2

1 NVME M.2

FAN

1 x 1*3PIN SYS_FAN, 1 x 4pin CPU _ fan.

JLPC

1 2*5Pin pin

PCIE

2 PCIE slots and 1 PCIEx16；; 1 PCIEx1

environment

temperature range

working environment

Storage environment

Temperature:-10 ~ 60℃ Humidity: 5%~95%

Temperature: -40~85℃ Humidity: 5%~95%

Physical size

measure

170 mm x 190 mm
